17

45

SETTING THE SHOCK REBOUND TO 50% & 0%
(MEDIUM REBOUND & LOW REBOUND)

46

ASSEMBLY OF THE SHOCKS SPRING

47

ASSEMBLY OF THE SHOCKS
INTO THE SHOCK STAY

Step 1

Step 2

TIGHTENED HALF WAY 50%

50%

TIGHTENED 100%

50%

Step 3

Step 1

Step 2

Step 3

TIGHTENED HALF WAY 50%

TIGHTENED 100%

Step 1

Step 2

Step 3

Cut 7mm

40058

41015(SHORT)

41008

41008

41015(LONG)

Step 1

Step 2

REAR SHOCK

FRONT SHOCK

40058

94040
3x8x0.8mm
Washer

.....x4

94041
3mm Nylon Nut

.....x4

94007
3x20mm
Hex Screw

.....x4

3x20mm

40643

FRONT SHOCK

REAR SHOCK

3x20mm

40643

3x8x0.8mm

3mm

3mm

3x8x0.8mm
