10
Step 3
28
..........X3
ASSEMBL OF THE CENTER DIFF. MOUNT Y
40040
Center Diff.
Mount
36661
Brake Pad
40040
Center Diff.
Mount
40662
Center Diff.
Mount Post
40666
Fiber Glass
Brake Disk
Center Diff.
Assemble
Approx. 3.5mm
¬ù
3 .5 m m
94004
3x12mm
Hex Screw
94003
3x10mm
Hex Screw
8mm
Approx. 8mm
¬ù
8 m m
30212
Flange
Ballbearing
..........X2
..........X3
..........X2
94033
3x3mm
Set Screw
94033
3x3mm
Set Screw
40665
Brake Cam
30171
Brake Lever
40665
Brake Cam
30212
5x8mm
Flange Bushing
4063160
Brake Pad
94004
3x12mm
Hex Screw
40666
Fiber Glass
Brake Disk
40044
Brake Pad
Spring
Step 2 Step 1
Step 4
Step 5
Step 6
3x15mm
Hex Screw
94033
3x3mm
Set Screw
94003
3x10mm
Hex Screw
40676
Center Diff. Mount
Post Washer 40676
Center Diff. Mount
Post Washer
Approx. 4mm
¬ù
4 m m
40676
Fuel Filter
Spacer
40099
Clip for
Fuel Filter
30171
Brake Lever
40569
Graphite
Center Diff.
Mount Plate
*Makes two for Front and Rear.
