Page 27
20
55
Step 1
Step 2
..........X4
57
ASSEMBLY OF THE FUEL TUBE
Connect to
carbulater.
Connect to
fuel nipple.
Connect to fuel
tank nipple.
Connect to pressure
nipple.
10179
Fuel Tube
IN
S
TA
N
T
G
L
U
E
Apply instant glue into the groove of the wheel.
56
ASSEMBLY OF THE TIRES AND WHEELS
Make two tires right-side .
80020
Tires
81095
Inner Sponge
86040
Wheel
(Yellow)
Tire and Wheel
assembly.
40526
Wheel Nut
40526
Wheel Nut
ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB
Assembly for both right and left side
10166
