OFNA Racing Jammin X1 CR FTE - Manual (Page 21)

10114
Engine Mount
Screw
10114
5mm
Engine Mount
Screw
45
44
43
Step 1 Step 2
..........X1
..........X1
..........X4
..........X1
ASSEMBL OF THE MANIFOLD AND MUFFLER Y
ASSEMBLY OF THE ENGINE ONTO CHASSIS
Spur Gear
Clutch Bell
Loose or tighten 3x20mm cap screw
and 5x10mm hex screw to align spur
gear and clutch bell gear to 90 degree.
90 degree
4x10mm
Flat Head
Hex Screw
4x10mm
Flat Head
Hex Screw
5x4mm
Set Screw
3x3mm
Set Screw
3x3mm
Set Screw
A-80B
Adjust Mount
30801
Servo
Mount
#312
Servo Horn
3x3mm
Set Screw
30801
2mm
Adjust nut
30172
2X65mm
Rod
30172
2X65mm
Rod
ASSEMBLY OF THE THROTTLE LINKAGE (TypeA)
2X8mm
Screw
2.6x18mm
Screw
2mm
Nut
M2.5
Nylock Nut
Cut off the servo saver as shown.
Use note book paper to set gear backlash
between spur gear and clutch bell gear,
applying pressure while retightening the
engine.
If the space is notcorrect the spur gear
will be damaged.
Notice the direction of the adjust nut.
Adjust the height with
3x6.4x1mm washer.
40050
Muffler Stay
Post
#139
Manifold
Spring
A-80B
Adjust Mount
1/8 In-line Pipe
JP-1 #10054
JP-2 #10045
(Option)
Manifold and muffler are not included in kit.
95700
1/8 Sprin0g
(Option)
95700
1/8 Seal,
Silicone
(Option)
97510
Manifold,
Round Style
(Option)
..........X2
..........X2
..........X1
..........X2
3x3mm
Set Screw
30801
2mm
Adjust Nut
M2.5
Nylock Nut
M2
Nut
2X8mm
Hex Screw
2.6X18mm
Hex Screw
..........X2
..........X1
Type A
40549
Muffler stay
5x4mm
Set Screw
94033
94036
94026
94033
94036
94026
94033
94033
#30801 Linkage kit, 2 Knobs, kit
