Page 10

Assembly for both left and right side.

ASSEMBLY OF THE FRONT SHOCK STAY

3x15mm
Hex Screw

36742
Bushing

39242
5x8x2.5mm
Ball Bearing

40719
Shock Mount(A)

40719
Shock Mount(B)

*Notice"L"make are for
inside.

ASSEMBLY OF THE FRONT SHOCKS ONTO SHOCK STAY

94041
3mm
Nylon Nut

94040
3x8mm
Washer

40643
Shock Cap
Washer

.....x2

40643
Shock Cap
Washer

3x8mm
Washer

3mm
Nylon Nut

3x12mm
Hex Screw

Step 1

Step 2

ASSEMBLY OF THE REAR UPPER ARMS

¡G

36850
7mm
Ball

36861
5x35mm
Turnbuckle

40537
Rear Upper Arm

40719
Upper Arm
Adjuster

40719
Rear Upper Arm
Holder (Plastic)

4x16mm
Hex Screw

.....x2

36850
7mm
Ball

40065
Upper Arm
Plastic Rod End

.....X2

.....X4

39242
5x8x2.5mm
Ball Bearing

36742
Shock Cap
Bushing

Approx. 12.5 mm

94005
3x16mm
Hex Screw

.....x2

94004
3x12mm
Hex Screw

.....x2

94011
4x16mm
Hex Screw

.....x2

*Take the shock cap washer
from the shock plastic tree.

Ensure
Free
Movement

*Set the left and right hand side upper
arm adjuster in the same direction.

Left

Right

Do Not
Over Tighten

Assembly for both left and right side.
