FIGURE A
SKU 90186 PAGE 8
2. The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the tool. The green wire in the cord must be the
only wire connected to the tool’s grounding system and must never be attached
to an electrically “live” terminal. (See Figure A.)
3. Your tool must be plugged into an appropriate outlet, properly installed and
grounded in accordance with all codes and ordinances. The plug and outlet
should look like that in the following illustration. (See Figure A.)
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
4. Tools marked “Double Insulated” do not require grounding. They have a
special double insulation system which satisfies OSHA requirements and
complies with the applicable standards of Underwriters Laboratories, Inc., the
Canadian Standard Association, and the National Electrical Code.
(See Figure B.)
5. Double insulated tools may be used in either of the 110 volt outlets shown in the
following illustration. (See Figure B.)
FIGURE B
