Wilbur Curtis GSG-3RED - Manual (Page 3)

3
ELECTRICAL SCHEMA ELECTRICAL SCHEMA ELECTRICAL SCHEMA ELECTRICAL SCHEMA ELECTRICAL SCHEMATIC TIC TIC TIC TIC
Item Part No. Description
MOTOR ASSY, HOUSING./FEEDWORM/SHEAR GSG
SPRING, TENSIONING
FEED WORM ASSY, CCG
SHEAR DRIVE GRINDER
DISK, SHEAR COFFEE GRINDERS
SCREW, CAP 10-32 BINDER HEAD
CAP, SHEAR DISK GRINDERS
BURR, SET CRUSH FINE COFFEE GRINDERS GSG
SCREW, 5/16-18 X 1” SLOT PAN HEAD
SPRING, CAP DETENT
CAP, SPRING DETENT
LABEL, SELECTOR RING GSG
SCREW, ADJUSTING ASSY GSG
RING, DETENT GSG
SCREW, 10-32 X 3/8 PAN HEAD
WASHER, #10 FLAT, SS
KNOB, SELECTOR
SCREW, 1/4-20 X 1” SET SLOTTED
LABEL, SELECTOR KNOB GSG
COVER, HOUSING
SPOUT ASSY, HOUSING GSG WC-91063
WC-9106
WC-9102
WC-9109
WC-9107
WC-4826
WC-9108
WC-91019
WC-4613
WC-9175
WC-9174
WC-39045
WC-9199
WC-9172
WC-4512
WC-4309
WC-9171
WC-4832
WC-39046
WC-9170
WC-6671 10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30 15
13
12
14
PARTS DIAGRAM
MOTOR ASSEMBLY
11
10
16
17
22
21
20
19
18
23
29
28
27
26
25
24
30
B
