Parts list – Wilbur Curtis G4TPC2T User Manual
Page 10
10
ITEM NO.
PART NO.
DESCRIPTION
1
WC-61289
COVER, TOP
2
WC-61284
PANEL, L SHAPE, LEFT
3
WC-61286
PANEL, CENTER SECTION, LEFT
4
WC-1853*
FAUCET, ASSY TPC (MILANO)
5
WC-37259*
KIT, BREW CONE GOURMET NON-METAL WITH “FRESH COFFEE” LOGO
6
WC-37308*
KIT, BREW CONE GEMINI NON-METAL WITH “FRESH COFFEE” LOGO
7
WC-14045-101*
CURRENT SENSOR ASSY G4
8
WC-8559*
RELAY, SOLID STATE 40A w/INTEGRATED HEATSINK
9
WC-3528
LEG, 4” ADJUSTABLE 3/8-16 THREAD STYLIZED
10
WC-61290
COVER, CENTER WRAP
11
WC-61287
PANEL, INTERSECTION, RIGHT
12
GEM-6 *
FILTER, 500PK GEM-12/230A
12A
GEM-6-101*
FILTER, PAPER 15 x 5-1/2 x 4-3/4
13
WC-2402P*
ELBOW, 3/8 NPT x 3/8 FLARE PLATED
14
WC- 847*
VALVE, INLET 2 GPM 120V-10W
15
WC-1501
FUSE, HOLDER ASSY w/5A FUSE
16
WC- 102*
SWITCH, TOGGLE SPST 15A 125Vac RESISTIVE
17
WC-61285
PANEL, L SHAPE, RIGHT
18
WC-37008*
KIT, TANK LID ROUND
19
WC-37406*
KIT, LIQUID LEVEL PROBE FAIL SAFE NON-METAL GEN
20
WC-43067*
O-RING, 4-1/2 I.D. x Ø.285 C.S. SILICONE
21
WC-5350*
TUBE, SILICONE Ø1/2” ID x Ø3/4” OD x 1/8” WALL
22
WC-5310*
TUBE, SILICONE Ø5/16” ID x Ø9/16” OD x 1/8” WALL
23
WC-62030*
TANK COMPLETE, 220V, (3) 2500W ELEMENT, 6.89 GALLONS
24
WC- 934-04*
KIT, ELEMENT HEATING 2.5KW 220V W/ JAM NUT & SILICONE WASHERS
25
WC-1438-101*
SENSOR, TEMPERATURE TANK
26
WC-4382
GUARD, SHOCK (HEATING ELEMENT)
27
WC- 522
THERMOSTAT, HI LIMIT HEATER DPST 277V-40A
28
WC-43055
GUARD, SHOCK RESET THERMOSTAT
29
WC- 821WDR*
VALVE, DUMP LEFT 120V-14W w/INTERNAL RESISTOR & DIODE
30
WC- 442*
SOLENOID, LOCK BREW CONE RIGHT 120VAC
31
WC- 589-101
TRANSFORMER, 120/230VAC - 24VAC 4.8VA w/LEADS & TERMINALS
32
WC-844-101*
VALVE, BYPASS 120V-14W NON ADJUSTABLE w/RESTRICTOR (WC-2945)
33
WC-13450
HARNESS ASSY, COMPLETE TP2T10G4/GEMTS10G4/GEMTIF10G4
34
WC- 820WDR*
VALVE, DUMP RIGHT 120V-14W w/INTERNAL RESISTOR & DIODE
35
WC-2977-101*
FITTING, SPRAYHEAD ULTEM
36
WC-4306-103*
WASHER, 7/8OD x 9/16ID x 3/32 THK, SNGL-D, SILICONE
37
WC-4212-02
NUT, 5/8-18 JAM PLASTIC-ULTEM
38
WC-29050
SPRAYHEAD ASSY, AFS-AMBER
39
WC-10008
UNIVERSAL HOST ADAPTER (USB)
40
WC-39811
LABEL, OUTER TOUCH SCREEN TP2T CURTIS LOGO
41
WC-10000*
CONTROL MODULE, TOUCH SCREEN G4
42
WC-10001*
UNIVERSAL POWER MODULE - G4
Parts List
* RECOMMENDED PARTS TO STOCK
