Wilbur Curtis TPC2T - Manual (Page 4)

4
1
2
2A
3
3A
4
5
6
7
8
9
10
11
11A
12
12A
13
14
15
15A
16
17
18
18A
19
19A
20
20A
21
22
23
24
25
26
27
28
29
30
31
31A
32
33
34
35
36
37 WC-61289
WC-37121*
WC- 859
WC- 442
WC- 446
WC-61284
WC-2977-101K*
WC-61286
WC-29050*
WC-1853
WC-8591*
WC-3528
GEM-6
GEM-6-101
WC-3417
WC-3422
WC-61287
WC-37132*
WC- 37176
WC- 728
WC-39496-101
WC-39496
WC- 844-101*
WC- 844-102
WC-37122*
WC- 854
WC- 847*
WC- 883
WC-37008
WC-2402P
WC-5502-01*
WC-5350*
WC-62030
WC- 934-04*
WC-4382
WC- 522*
WC-43055
WC-1501
WC- 102*
WC- 103
WC-8559
WC-61285
WC-5310*
WC-3765L*
WC-5231*
WC-1438-101* COVER, TOP WRAP
KIT, DUMP VALVE LEFT 120V 14W
VALVE, INLET .35GPM 240V 10W
SOLENOID, LOCK BREWCONE RIGHT/LEFT 120V TP2T/TP2S/GEM
SOLENOID, LOCK BREW CONE RIGHT 220V THERMOPRO/GEMT
PANEL, L’ SHAPE LEFT
KIT,SPRAYHEAD FITTING PLASTIC
PANEL, CENTER SECTION LEFT
SPRAYHEAD, AMBER ADVANCED FLOW
FAUCET, ASSEMBLY TPC
CAPACITOR
LEG, 4” ADJUSTABLE
FILTER, 500PK 12½ x 4 GEMSS/GEMTS/TP
FILTER, PAPER 15 X 5-½” ALTRA 4-3/4” H USED ON WC-3422
BREW CONE ASSY, W/SPLASH POCKET BROWN HOT COFFEE
BREW CONE,ASSY W/SPLASH PCKT BRN STYLIZED HIGH VOL
PANEL, CENTER SECTION RIGHT
KIT, VALVE REPAIR USE ON WC-37122 & WC-37121
KIT, UCM & LABEL INSTRUCTIONS TP
CONTROL MODULE, 220V TP2S/TP2T GEMSS/GEMTS
LABEL, UCM OUTER MILANO
LABEL, UCM OVERLAY MILANO 3-BATCH
VALVE, BY-PASS W/RESISTOR
VALVE, BY-PASS, 220V NON-ADJUS TABLE W/ RESTRICTOR
KIT, DUMP VALVE RIGHT 120V 14W
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/TP/TPC
VALVE, WATER INLET 2GPM 120V 10W
VALVE, INLET 2 GPM 240V 10W
KIT, TANK LID ROUND
ELBOW, 3/8”FL x 3/8” NPT PLATED
KIT, PROBE, ASSY WATER LEVEL W/HEX FITTING, O-RING & NUT
TUBE, ½” ID x 1/8W SILICONE
TANK, COMPLETE TP2T ULTEM FITTINGS
KIT,ELEMENT HEATING 2.5KW 220V W/ JAM NUT & WASHERS
GUARD, SHOCK HEATING ELEMENTS
THERMOSTAT, RESET
GUARD, SHOCK RESET THERMOSTAT
FUSE HOLDER ASSY W/5A FUSE
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A 250VAC RESISTIVE
SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC RESISTIVE
RELAY, SOLID STATE W/INTEGRATED HTSNK
PANEL, L’ SHAPE RIGHT
TUBE, 5/16” I.D. X 1/8” SILICONE
KIT, VALVE REPAIR WATER INLET
COMPOUND, SILICONE
SENSOR, HEATING TANK
Part № Description
* Recommended parts to stock.
Item №
Parts List
