Page 3
■
Package Contents
① Main unit ZIG-CX-100 Rx.
② Main unit ZIG-CX-100Tx.
③ Operating instructions.
④ 2x 5V 3A DC power supply.
⑤ 1xIR TX unit. (IR emitter cable)
⑥ 1xIR RX unit. (IR receiver cable)
NOTE: PART NUMBER (Abbreviation as P/N)
■
Connections and Operations
1) Connect the HDMI input source ( such as HD-DVD、PS3、STB etc. ) to
ZIG-CX-100 Tx.
2) Connect a COAX cable from SDI OUT1/SDI OUT2 of ZIG-CX-100 Tx to
SDI input of ZIG-CX-100 Rx.
3) Connect the HDMI sink ( such as HD-LCD、HD-DLP)
to ZIG-CX-100 Rx.
4) Connect the IR TX UNIT into ZIG-CX-100 Rx (IR TX); Connect the IR RX
UNIT into ZIG-CX-100 Tx (IR RX).
Attention: Please insert and extract cables gently.
