INSTALLATION
2-3
Figure 2-2. Installing the BRIM-T6
5. Insert the connector pins on the underside of the BRIM into the
motherboard connector on the MIM by pressing down firmly on the
rear section of the BRIM until the pins slide all the way into the
connector holes.
6. Fasten the BRIM securely to the MIM motherboard with the
coverplate and standoff screws.
See Section 2.4 for TPIM configuration and installation instructions.
BRIM T6
16Mb
XMT
STB
RCV
Standoff screw
Coverplate
screw
Connector
Connector pins
under BRIM
