Damping and Hysteresis
Transducer power modulation (XPM)
Used to reduce current in sender circuit
Output signal format
Outputs are capable of sinking or sourcing up to 1mA,
maximum (50
µ
A maximum is standard)
The 5V-0 output signal format is fully compatible with
the Curtis Model 1178 relay module.
3.2 Mechanical
Terminals (Spade) 6 ANSI/NEMA 0.25 inch male fast-ons
Dimensions
Bezel diameter 58.8 mm, maximum
Case diameter 51.5 mm, maximum
Depth 45.0 mm, maximum
(includes mounting studs)
Weight 70g, maximum
Lens Material Glass (plastic lens optional)
Case Material Black polycarbonate
