Output signal trigger point (lower)
First LED
Second LED
Output signal trigger point (upper)
Ninth LED
Tenth LED
Output signal format—(upper and lower independently set)
0-5 V
5-0 V*
LED flashing mode (lower)
No flashing
First LED flashes alone
First LED or second flashes alone
Both first & second flash out of phase*
LED flashing mode (upper)
No flashing
Tenth LED flashes alone
Both tenth & ninth flash in phase
Both tenth & ninth flash out of phase*
* indicates standard setting
