Terminal Assignment for
Model 2114R
1 Not Connected **
2
Battery +
3 Ground
4 Not Connected**
5 Output signal (upper)
6 Output signal (lower)
Terminal Assignments for Models 2211R,
2212R, 2213R
1 Sender in
2 Battery +
3 Ground
4 Hourmeter enable*
5 Output signal (upper)
6 Output signal (lower)
!
12
