Transmitter Range Chart
(Note: These distances are approximate.)
Boundary Control
Dial Position
Boundary Switch LOW Boundary Switch HIGH
1 1.5 m to 3 m (5 ft to 10 ft) 1.5 m to 3 m (5 ft to 10 ft)
2 1.5 m to 3 m (5 ft to 10 ft) 1.5 m to 3 m (5 ft to 10 ft)
3 4.5 m to 6 m (15 ft to 20 ft) 7.5 m to 10.5 m (25 ft to 35 ft)
4 6 m to 7.5 m (20 ft to 25 ft) 12.5 m to 16.5 m (42 ft to 55 ft)
5 7.5 m to 9 m (25 ft to 30 ft) 16.5 m to 19.5 m (55 ft to 65 ft)
6 10.5 m to12 m (35 ft to 40 ft) 23 m to 26 m (75 ft to 85 ft)
7 12 m to 13.5 m (40 ft to 45 ft) 26 m to 27.5 m (85 ft to 90 ft)
8 12 m to 13.5 m (40 ft to 45 ft) 26 m to 27.5 m (85 ft to 90 ft)
Record Your Settings
Final Boundary Switch
Setting (HIGH or LOW) Final Boundary Control
Dial Position (1-8)
Receiver Static
Stimulation Level (1-6)
Home
Camping
Vacation
Other
STEP 4
Place the Boundary Flags
The Boundary Flags are visual reminders for your pet of where
the Boundary Zone is located. The Receiver Collar will activate
within 0.6 m to 1 m (2 ft to 3 ft) of the Boundary Flags.
1. Using the Test Light, with the Static Stimulation Level
set at 2 or greater, hold the Receiver Collar at your
pet’s neck height with the PetSafe
® logo facing away from
the Transmitter.
2. Walk towards the Boundary Zone until the Receiver Collar
beeps and the Test Light fl ashes (4A).
3. Place a Boundary Flag in the ground (4B).
4. Walk back into the Pet Area until the beeping stops.
5. Repeat this process around the Boundary Zone until it is marked with Boundary Flags every
3 m (10 ft).
H A P P Y O W N E R S S A F E P E T S
4A 4B
