Petsafe DIY Box Kennel - 2.29 m (W) x 2.29 m (D) x 1.82 m (H) - Manual (Page 3)

-3-
Step 8 Install the gate.
1. Gather male and female hinges, 4 - 3 /
8
" x 2" carriage bolts with nuts, and the gate.
Note: Gate can open from either side.
2. Install the upper female hinge below the upper most gate clip (8B).
3. Install the lower female hinge directly above the bottom gate clip (8C).
4. Position the gate centered in the gate opening.
5. Attach bottom male hinge and slide up to meet bottom female hinge. Tighten securely (8C).
6. Attach top male hinge and slide down to meet top female hinge. Tighten securely (8B).
7. With an adjustable wrench, install the gate latch 36" from the ground (8A). Note: The gate
latch can be locked. Lock not provided.
Next put on the fence fabric.
Note: Putting the fabric on is easy, except chain link fabric is strong and stiff and the roll is
heavy, so a helper is recommended.
Tools needed
Step 9 Add fence fabric.
Gather 5 clips, one tension rod, package of
tie wires, and the roll of wire.
Start at a
post next
to the gate.
Slip the tension rod down
through the first diamonds
of the fabric.
Connect the fabric to the
gate post by clipping the
tension rod to the post.
8A
8B
8C
