1/4 X 3
FLATTENED END HANGER
BOLTS
4 REQUIRED
Rize Quick Locks
4 REQUIRED
5
1/4-20 NYLOCK NUT
4 REQUIRED
4
CEILING PIPE
ADAPTER 1 ½”
1 REQUIRED
CEILING T-BAR PLATE
1 REQUIRED
9/32 ID X 5/8 OD
STEEL FLAT WASHER
4 REQUIRED
2
1 7
5/16 ID X 7/8 OD
STEEL FLAT WASHER
4 REQUIRED
9
1/4-20 X 3/4
CARRIAGE BOLT
4 REQUIRED
8
M6 X 16 PAN HEAD
PHILLIPS MACHINE
SCREW
4 REQUIRED
M6 X 10 PAN HEAD
PHILLIPS MACHINE SCREW
1 REQUIRED
3
6
1.50" CHROME TRIM
RING
1 REQUIRED
10
5/64ӯ X 8FT LONG WIRE
ROPE
4 REQUIRED
11
12
HARDWARE
4
