STANDARD M2.5
STEEL FLAT WASHER
4 REQUIRED
1/4 X 1/2 X 3/16
PLASTIC SPACER
8 REQUIRED
SECURITY TORX BIT T27
1 REQUIRED
STANDARD M4
STEEL FLAT WASHER
4 REQUIRED
9/32 X 47/64 X 1/16
PLASTIC FLAT WASHER
4 REQUIRED
"Z" BEND
OFFSET ADAPTER
4 REQUIRED
1/4-20 X 5/8 TRUSS HEAD
PHILLIPS MACHINE SCREW
4 REQUIRED
M2.6-0.45 X 16 CHEESE HEAD
SLOTTED MACHINE SCREW
4 REQUIRED
M3-0.5 X 16 PAN HEAD
PHILLIPS MACHINE SCREW
4 REQUIRED
M4-0.7 X 16 PAN HEAD
PHILLIPS MACHINE SCREW
4 REQUIRED
3
MOUNTING HARDWARE
1 6
7
8
9
10
2
3
4
5
