Wall mount bracket…1 pc
A
B
D
E
Display bracket .... 2 pcs
G L
F K
C
H M
J
Locking bar... 2 pc
I
5mm x 16mm...4 pcs
Multi mount washer ...4 pcs
Plastic spacer 3/4 x 1”...4 pcs
5mm x 40mm... 4 pcs
6mm x 16mm...4 pcs 6mm x 40mm...4pcs
8mm x 16mm...4pcs 8mm x 40mm...4pcs
5/16” Flat washers...6 pcs
5/16’ x 2 ½”Lag bolts...6 pcs
MOUNTING ARM
PARTS LIST
Fig 1
TOP
BOTTOM
