13. Battery Disposal
29
Installing and Formatting a Hard Drive Technical Specifications
30
You can return your batteries free of charge to an authorized disposal station in your area.
Do not dispose of used batteries in household trash.
The LiPo rechargeable battery integrated in the Nexto-eXtreme must be removed from the
housing before disposal. Proceed with care using the screwdriver supplied with the unit, or
a similar small screwdriver. Remove both covers of the housing (unscrew 4 small screws).
Remove the small 2-pole plug (behind the hard drive connection) from the socket. The
LiPo rechargeable battery is located on the other side underneath the display. Remove it
with caution (it is fastened with a double-sided adhesive tape). Do not lift it with a sharp
tool.
14. Technical Specifications
Product Name
Model Name Nexto-eXtreme
ND2700
Built-in CF Slot
Built-in 4in1 Slot
Built-in
USB Hosting
Compact Flash type 1 and type 2 / MicroDrive
SD / SDHC / MMC / MMCPlus / MemoryStick /
MS Pro-HG / MS Pro MagicGate
xD type S and type M and type H
* with SD or MS adapter(not included)
- miniSD / TransFlash / MMC mobile / RSMMC
- MS Duo / MS Duo MagicGate / MS Pro Duo /
MS Pro Duo MagicGate
Mass storage devices : USB card reader /
Hard drive type camcorder /
Memory type camcorder
Still image capture devices: Digital camera
Memory Card
Support
Transfer Rate Memory card to ND2700 : Max. 66MByte/sec, Avg. 25MByte/sec
ND2725 to computer : eSATA avg. 60MByte/sec, USB avg. 25MByte/se
Hard Drive
Interface
2.5' SATA Hard drive Capacity up to 2,000GB
Battery Internal : 3.7V 1550mAH rechargeable Li-Poly battery.
60GB backup on a single charge
External : 3.7V 2200mAH rechargeable Li-Ion battery.
80GB backup on a single charge
* Rechargeable via USB or external power adapter.
Takes 5hr for full charge
External Power
Adapter : 100-240V AC to 5V/2A DC
USB : Runs on USB power from a computer
Computer
Interface eSATA : 3.0Gbit/sec, USB2.0 : 480Mbit/sec
File System Hard drive : FAT32, Memory Card : FAT12/16/32
OS
Compatibility Windows VISTA/XP/2000/ME/98SE, MAC OS 9.2 and later,
Linux2.4.18 and later
Dimensions 128mm(L) * 77mm(W) * 23mm(H) (5.03” * 3.03” * 0.91”)
Weight 130g (4.59oz) without a hard drive, 230g (8.11oz) with a hard drive
Accessories
USB cable / AC power adapter / Pouch/ Screw driver / 4 screws /
Manual / USB host adapter cable / eSATA cable
FCC Rules and Regulations – Part 15
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the
user's authority to operated the equipment under FCC rules.
