12. Technical Specifications
Sampling frequencies: ...................... 44.1, 48, 88.2, 96, 176.4, 192, 352.8*, 384kHz*
Resolution:........................................ 16 to 32 bits**
USB: ................................................. 2.0 high speed (USB 2.0 Audio compliant)
Clock precision: ................................ +/-10ppm 0 to 60°C, 2ppm typical @ 25°C
Analog input sensitivity: .................... 1.7V
rms
(0dBFS, gain = 0dB)
0.95mVrms (0dBFS, gain = 65dB)
Analog input impedance: .................. 47 kOhms
Analog input gain .............................. 0, 10-65dB (1dB steps)
S/PDIF input sensitivity: .................... 0.5Vpp +/-0.1V
S/PDIF input impedance: .................. 75 Ohms
S/PDIF output voltage:...................... 0.5Vpp +/-0.1V
S/PDIF output impedance:................ 75 Ohms
AES/EBU output voltage:.................. 2Vpp +/- 0.5V
AES/EBU output impedance:............ 110 Ohms
THD+N:............................................. 0.0004% (1kHz @ 0dBFS, f
s
=192kHz, 0-20kHz)
S/N ratio:........................................... 122dB (A-weighted, f
s
=384kHz)
Minimal requirements:....................... 1.3GHz CPU clock, 1GB RAM, 2.0 USB port
Supply voltage: ................................. 15V
DC
Power consumption: ......................... 290mA
Size: ................................................. 200x50x200mm (w x h x d, cabinet)
200x55x210mm (w x h x d, with connectors and feet)
360x120x260mm (w x h x d, box)
Weight:.............................................. 1.7kg (ADC only)
2.5kg (box)
* USB only.
** 32 bits are provided on USB output only.
