JOPLIN
384

/32bit ANALOG-TO-DIGITAL CONVERTER

REVISION P

B – SEPTEMBER 2012

M2Tech

www.m2tech.biz

INDEX

1. Unpacking and placing the unit........................................................................................6
2. Front Panel ......................................................................................................................7
3. Back Panel.......................................................................................................................8
4. Remote Control................................................................................................................9
5. Connecting and powering the unit .................................................................................10
6. Driver installation ...........................................................................................................11

6.1. Obtaining the driver .................................................................................................11
6.2. Installing the driver on a Windows-based PC..........................................................11
6.3. USB Control Panel ..................................................................................................16
6.4. Uninstalling the driver..............................................................................................17
6.5. True plug’n’play operation with Mac ........................................................................19
6.6. True plug’n’play operation with Linux ......................................................................19

7. Configuring the computer to use the Joplin...................................................................20

7.1. Configuring a PC with Windows XP ........................................................................20

7.1.1. Configuring for Direct Sound with Windows XP ................................................20
7.1.2. Configuring for ASIO with Windows XP ............................................................21

7.2. Configuring a PC with Windows Vista or Windows 7...............................................21

7.2.1. Configuring for Direct Sound with Windows Vista or Windows 7 ......................22
7.2.2. Configuring for Kernel Streaming with Windows Vista or Windows 7 ...............22
7.2.3. Configuring for ASIO with Windows Vista or Windows 7 ..................................23
7.2.4. Configuring for WASAPI with Windows Vista or Windows 7 .............................23

7.3. Configuring a Mac ...................................................................................................23

8. Configuring the JOPLIN ...................................................................................................24

8.1. Navigating the menu by the front panel controls .....................................................24
8.2. Navigating the menu by the IR remote ....................................................................24
8.3. Parameters meaning and choices ...........................................................................25

8.3.1. Input gain ..........................................................................................................25
8.3.2. Input choice ......................................................................................................25
8.3.3. Sampling frequency ..........................................................................................26
8.3.4. Resolution.........................................................................................................26
8.3.5. Equalization curve ............................................................................................27
8.3.6. Display dimming ...............................................................................................27
8.3.7. High pass (anti-rumble) filter.............................................................................27
8.3.8. Low pass (anti-hiss) filter ..................................................................................27
8.3.9. MPX filter ..........................................................................................................28

9. Notes on equalization ....................................................................................................30

9.1. Why equalization is needed for records? ................................................................30
9.2. List of phono equalization curves available on the Joplin and notes on their usage......33

9.2.1. RIAA .................................................................................................................33
9.2.2. AES ..................................................................................................................33
9.2.3. Angel (ANG) .....................................................................................................34
9.2.4. Audiophile (AUDP)............................................................................................34
9.2.5. Capitol (CAP)....................................................................................................34
9.2.6. Columbia (COL)................................................................................................34
9.2.7. HMV..................................................................................................................34
9.2.8. Decca/London FFRR ........................................................................................34
9.2.9. MGM.................................................................................................................34
