17. Technical Specifications
Sampling frequencies: ...................... 44.1, 48, 88.2, 96, 176.4*, 192*, 352.8**, 384kHz**
Resolution:........................................ 16 to 32 bits***
USB: ................................................. 2.0 high speed
Clock precision: ................................ +/-1.5ppm 0 to 60°C, 0.1ppm typical @ 25°C
External clock frequencies ................ 44.1, 48, 88.2, 96, 176.4, 192, 352.8 and 384kHz,
22.5792 and 24.576MHz
External clock input level .................. 3.3V
S/PDIF input sensitivity: .................... 0.5Vpp +/-0.1V
S/PDIF input impedance: .................. 75 Ohms
AES/EBU input sensitivity: ................ 2Vpp +/- 0.5V
AES/EBU input impedance: .............. 110 Ohms
I
2
S input level .................................... LVCMOS/TTL (3.3V)
S/PDIF and AES/EBU inputs bit-rate up to 24.576Mbps (up to 384kHz sampling
frequency in dual mono mode)
ST inputs bit-rate .............................. up to 24.576Mbps (up to 384kHz sampling
frequency in dual mono mode)
Toslink™ input bit-rate: ..................... up to 15Mbps (up to 192kHz sampling frequency
in dual mono mode)
I
2
S input bit-rate ................................ up to 24.576Mbps (up to 384kHz sampling
frequency)
Analog output voltage: ...................... 2.65V
rms
@ 0dBFS (single-ended)
5.3V
rms
@ 0dBFS (balanced)
THD+N:............................................. 0.0003% (1kHz @ 0dBFS, 0-22kHz)
S/N ratio:........................................... 128dB (A-weighted)
Volume control range........................ 0dB to -90dB, 0.5dB steps
Muting: .............................................. -20dB
Balance:............................................ 0dB to 6dB, 0.5dB steps
Minimal requirements:....................... 1.3GHz CPU clock, 1GB RAM, 2.0 USB port
Supply voltage: ................................. 90-265V
AC
, 50-60Hz
Power consumption: ......................... 75VA
Battery charge time........................... 4 hours +/- 0.5 hour
Battery duration ................................ 5 hours
Battery charge cycles........................ 1000 min. (up to 4000 in auto mode)
Size: ................................................. 450x90x450mm (w x h x d, cabinet)
450x100x465mm (w x h x d, with connectors and
feet)
550x150x550mm (w x h x d, box)
