Home Styles 5552-83 - Manual (Page 2)

Figure 1
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Key Wrenches and Hex Wrench in a safe place as you may need to tighten up the Nuts and Head Cap Bolts
in the future.
* Use a soft cloth between the parts and the floor.
Figure 2
Insert all Bolts into the
pre-drilled holes of Seat (A). (See Figure1)
Attach Legs (F) onto Seat (A) with
Flat Washers (middle), Spring Washers (middle),
Nuts (middle) and Nut Caps.
STEP 1
Attach Arms (B) and (C) to
unit with Head Cap Bolts (large).
Attach Wheels (F) to unit with
Flat Washers (large),
Spring Washers (large) and Nuts (large).
(See Figure 2)
STEP 2
Nut Cap
Nut (large)
Wheel Bolt
Nut (middle)
Flat Washer (large)
Flat
Washer (middle)
Spring Washer (large)
Spring
Washer (middle)
B
A
Assembly Instructions 2/3
F
F
A
C
G
G
Head Cap Bolt (large)
Large Key Wrench
Nut (large)
Spring Washer (large)
Flat Washer (large)
Wheel Bolt
Plastic Ring is on
outside of wheel
