Home Styles 5003-89 - Manual

Part List
Counter Stool
Casual Oak & Black
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Hardware List
Tools required for assembly :
Phillips screwdriver
A.
Seat
1 pc.
D.
Back Frame
. 1 pc
F.
Side Stretcher
1 pc.
E.
Side Stretcher
1 pc.
Head Cap Bolt
4 pcs.(+1 extra)
Spring Washer
11 pcs.(+1 extra)
Flat Washer
11 pcs.(+1 extra)
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
[email protected]
Head Cap Bolt
(long)
4 pcs.(+1 extra)
Wood Screw
6 pcs.(+1 extra) Head Cap Bolt
(Short)
3 pcs.(+1 extra)
B.
Leg
1 pc.
C.
Leg
1 pc.
G.
Front Stretcher
1 pc.
88 5003 89
Key Wrench
1 pc.
Small
Hex Wrench
1 pc.
