Assembly Instructions 3
STEP 3
Attach Connecters at the pre-drilled holes
in Shelves (F) with Wood Screws.
STEP 4
Attach Shelves (F)
to unit with
Head Cap Bolts (short),
Spring Washers and
Flat Washers.
Attach Side Panel (E) to unit
with Head Cap Bolts (short),
Head Cap Bolts (long),
Spring Washers and
Flat Washers.
STEP 5
Place Top (A) onto unit with
Head Cap Bolts (long), Spring
Washers and Flat Washers.
To level the unit, adjust the
adjustable levelers on the
bottom of unit.
(See fi gure 2)
Note: Unit must be level to work properly.
B
F
B F
B
E
B
F
B
F
B
A
Wood Screw
Connecter
Flat Washer
Spring Washer
Head Cap Bolt (short)
Head Cap Bolt (long)
Spring Washer
Flat Washer
Flat Washer
Spring Washer
Head Cap Bolt (long)
Figure 2
