Assembly Instructions 2
IMPORTANT
* Please keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Do not tighten up all the bolts until each part is properly assembled.
* Use a soft cloth between these parts and the fl oor.
STEP 1
Attach Front Panel (C) to Front Panel (B)
with Head Cap Bolts (long),
Spring Washers and Flat Washers.
(See fi gure 1)
STEP 2
Attach Side Panel (D) to unit
with Head Cap Bolts (long),
Spring Washers and Flat Washers.
B B
B
D
B
C
Head Cap Bolt (long)
Spring Washer
Flat Washer
Flat Washer
Spring Washer
Head Cap Bolt (long)
Figure 1
