Assembly Instructions 2/4
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
STEP 1
Insert Cam Lock Screws
into the pre-drilled holes of Top (A).
STEP 2
Insert Cam Lock Screws into the pre-drilled holes of Side Panel (B) and (C) and
Middle Panels (D), (E).
A
B
C
D
E
Cam Lock Screw
Cam Lock Screw
Cam Lock Screw
