Home Styles 5516-06 - Manual (Page 4)

Assembly Instructions 4
H1.
Front Part
2 Pcs. H2.
Back Part
2 Pcs. H3.
Side Part
2 Pcs. H4.
Side Part
2 Pcs. H5.
Side Part
2 Pcs.
Part List
STEP 2
Slide H5 into the grooves in H3 and H4.
Be sure to push H5 all the way forward so it meets H1.
(see Figure 2)
STEP 3
Insert short wood screws (4X) into the
pre-drilled holes in H5 and tighten.
(see Figure 3)
STEP 4
Assemble Pull Handle with machine screws.
(see Figure 4)
Tighten all screws used in drawer assembly.
STEP 1
Attach H1 to H3 and H4, using a Phillips screwdriver and long wood screws (4X), tighten halfway.
Attach H2 to H3 and H4 using long wood screws (4X), tighten
halfway. (see Figure 1)
