Introducing the Enclosure 1–5
Figure 1–3. Front Mounted Elements
The I/O module, power supplies, fans, EMU, and cables mount in the rear of the enclosure
(see Figure 1–4).
Figure 1–4. Rear Mounted Elements
1
EMU
2
Fan 1
3
Power Supply Bay 1, or
Fan Mounting Assembly 1
1. In a single power supply configuration, the fan mounts on the fan mounting assembly.
4
Fan 2
5
Power Supply Bay 2
6
I/O Module
CXO6728A
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15
CXO6979A
1 2 3 4 5 6
