PARTS LIST
(Replaces pg. 30 in instruction manual.)
PART NAME AND DESCRIPTION
1. Draft hood 15A. Resettable Thermal Switch
2. Setback Control Junction Box Assembly 16. Left side inner door
3. Jacket head 17. Accessory Module
4. Jacket 18. Junction box wire harness
5. Heat trap (outlet) 19. Thermal well
6. Anode Outlet Device 20. Gas control
7. Heat trap (inlet) 21. FV sensor / RTS wire harness
8. Baffle 22. FV sensor clip
9. Diptube 23. FV sensor
10. T&P valve 24. Outer door
11. Tank 25. Burner
12. Combustion chamber 26. Orifice
13. Pedestal base 27. Pilot assembly
14. Drain valve 28. Main burner feedline
15. Right side inner door
