Specifications

Part II-Venting Specifications for:

40 Gallon

50 Gallon

Through the Wall

Terminating

# of

Elbows

(excl. vent

term.)

Maximum

straight

Length ft

(m)

VENT CONNECTOR LENGTHS FOR 2"

(5.1 cm) DIAMETER VENT PIPE

1

30

(9.1)

Through the Wall

2

25

(7.6)

Through the Wall

3

Through the Wall

4

15

(4.6)

Through the Roof

0

35

(10.7)

Through the Roof

1

30

(9.1)

Through the Roof

2

25

(7.6)

Through the Roof

3

20

(6.1)

Vent Tables

Page 8

PDX Series

Minimum

straight

Length ft

(m)

2 (.6)
2 (.6)
2 (.6)
2 (.6)

7 (2.1)
7 (2.1)
7 (2.1)
7 (2.1)

IMPORTANT

The minimum equivalent length for the exhaust portion of the vent is 7 feet. The maximum equivalent vent length for the exhaust is 35 feet
for 2" diameter pipe and 85 feet for 3" diameter pipe. The intake portion of the vent must be equal to or less than the vent length of the
exhaust. The tables below are provided for your quick reference, some installations may require a greater number of elbows. When
calculating equivalent vent length, one 90° elbow is equivalent to 5 feet.

20

(6.1)

Through the Wall

Terminating

# of

Elbows

(excl. vent

term.)

Maximum

straight

Length ft

(m)

VENT CONNECTOR LENGTHS FOR 3"

(7.6 cm) DIAMETER VENT PIPE

1

80

(24.4)

Through the Wall

2

75

(22.9)

Through the Wall

3

Through the Wall

4

65

(19.8)

Through the Roof

5

60

(18.3)

Through the Roof

0

85

(29.9)

Through the Roof

1

80

(24.4)

Through the Roof

2

75

(22.9)

Maximum

straight

Length ft

(m)

10 (3.1)
10 (3.1)
10 (3.1)
10 (3.1)
10 (3.1)
15 (4.6)
15 (4.6)
15 (4.6)

70

(21.3)

Through the Roof

Through the Roof

3

70

(21.3)

65

(19.8)

4

15 (4.6)
15 (4.6)

8
