B&C Technologies SI Series Industrial - Manual (Page 28)

Never touch internal or external steam pipes, connections, or components. These
surfaces can be extremely hot and will cause severe burns. The steam must be
turned off and the pipe, connections, and components allowed to cool before the
pipe can be touched.
Table 5.7: Steam Service Consumption Data
MODEL Units SI-110
STEAM INLET and CONSUMPTION:
Steam inlet size
DN in 20 3/4
Required steam to heat bath 10F (6C)LOW kg lbs 3.15 7
Required steam to heat bath 10F (6C)HIGH kg lbs 4.77 10.5
Average Steam consumption per cycle kg lbs 72 158
MODEL Units SI-135
STEAM INLET and CONSUMPTION:
Steam inlet size
DN in 20 3/4
Required steam to heat bath 10F (6C)LOW kg lbs 3.8 8.4
Required steam to heat bath 10F (6C)HIGH kg lbs 5.8 12.76
Average Steam consumption per cycle kg lbs 88 194
MODEL Units SI-200
STEAM INLET and CONSUMPTION:
Steam inlet size
DN in 25 1
Required steam to heat bath 10F (6C)LOW kg lbs 5 11
Required steam to heat bath 10F (6C)HIGH kg lbs 7.7 16.9
Average Steam consumption per cycle kg lbs 117 194
MODEL Units SI-275
STEAM INLET and CONSUMPTION:
Steam inlet size
DN in 25 1
Required steam to heat bath 10F (6C)LOW kg lbs 5.25 11.5
Required steam to heat bath 10F (6C)HIGH kg lbs 7.95 17.5
Average Steam consumption per cycle kg lbs 120 260
