GTX65 TECHNICAL SPECIFICATIONS:
Output Power Rating 65W RMS @5% THD, 8
Ω
, 120 VAC
Speaker Size and Rating (1) Custom Design 12”, 8
Ω
Input Impedance 470k
Ω
Total System Gain Solo Ch 110dB, all controls @10
Rhythm Ch 88dB, all controls @10
Clean Ch 58dB, all controls @10
CD Input 29dB
Maximum Input Signal Accepted 7 volts peak-to-peak
Solo Channel Shape Control Proprietary Circuit
Rhythm Channel Low Control 20dB range @ 80Hz
Mid Control 15dB range @ 1kHz
High Control 20dB range @ 10kHz
Clean Channel Low Control 36dB range @ 80Hz
Mid Control 15dB range @ 800Hz
High Control 40dB range @ 10kHz
Power Requirements 120 VAC, 60Hz, 90VA
100/115VAC, 50/60Hz, 90VA;
230VAC, 50/60Hz, 90VA
Size and Weight 17-1/2” H x 20” W x 11” D, 34 lbs.
The GTX65 is covered with a durable Tolex material: wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Crate continually develops new products, as well as improves existing ones. For this reason, the specifications
and information in this manual are subject to change without notice.
www.crateamps.com
@2003 SLM Electronics, a division of St. Louis Music, Inc • 1400 Ferguson Avenue • St. Louis, MO 63133
47-475-07 • 021803
GTX65
Three-Channel Guitar Amplifier with Advanced DSP
Declaration Of Conformity
#30, Effective 01-01-2001
Manufacturer’s Name: SLM Electronics
Production Facility: 11880 Borman Drive, St. Louis, MO 63146, USA
Production Facility: 700 Hwy 202 W, Yellville, AR 72687, USA
Shipping Facility: 1400 Ferguson Ave., St. Louis, MO 63133, USA
Office Facility: 1400 Ferguson Ave., St. Louis, MO 63133, USA
Product Type: Audio Amplifier
Complies with Standards:
LVD: 92/31/EEC, 93/68/EEC, & 73/23/EWG
Safety: EN60065
EMC: EN55013, EN55020, EN55022, EN61000-3-2,
& EN61000-3-3
Supplementary information provided by:
SLM Electronics - R & D Engineering
1901 Congressional Drive, St Louis, MO 63146, USA
Tel.: 314-569-0141, Fax: 314-569-0175
