Page 16 For technical questions, please call 1-800-444-3353. SKU 95004
pLEASE REAd THE FOLLOWIng CAREFULLY
THE MANUfACTURER AND/OR DISTRIBUTOR HAS PROvIDED THE PARTS LIST AND ASSEMBLy
DIAGRAM IN THIS MANUAL AS A REfERENCE TOOL ONLy. NEITHER THE MANUfACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS qUALIfIED TO MAkE ANy REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS qUALIfIED
TO REPLACE ANy PARTS Of THE PRODUCT. IN fACT, THE MANUfACTURER AND/OR DISTRIBUTOR
ExPRESSLy STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAkEN By
CERTIfIED AND LICENSED TECHNICIANS, AND NOT By THE BUyER. THE BUyER ASSUMES ALL RISk
AND LIABILITy ARISING OUT Of HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT Of HIS OR HER INSTALLATION Of REPLACEMENT PARTS THERETO.
pARTS LIST
part description Qty.
1 Guide Ruler 1
2 Rivet 2
3 Screw 1
4 Base 1
5 Screw (M6 x 16) 1
6 Angle Bracket 1
7 Orientation Block 1
8 Screw (M6 x 10) 1
9 Washer 1
10 Nut (M6) 1
11 Blade Housing 1
12 Screw 1
13 Laser Plate 1
14 Screw 1
15 Spring Washer 1
16 Washer 1
17 Laser Plate Cover 1
18 Outer Plate 1
19 Spring Pin (6 x 40) 1
20 Saw Blade 1
21 Inner Plate 1
22 Spindle 1
23 Key (3 x 10 x 7) 1
24 Screw (M4 x 8) 4
25 Safety Cover Plate 1
26 Safety Cover 1
27 Screw (M5 x 8) 3
28 Bearing (6001Z) 1
29 Bearing Holder 1
30 Orientation Steel Cover 1
31 Screw (M5 x 14) 3
32 Gear 1
33 Spring Washer (#5) 4
34 Wave Spring Washer (#12) 1
35 C-Ring (#12) 1
36 Oilless Bearing 1
37 Gear Box 1
part description Qty.
38 Spring 1
39 Spindle Lock 1
40 Spring 1
41 Safety Cover Wrench 1
42 C-Ring (#10) 1
43 Nut (M6) 1
44 Depth Lock 1
45 Large Washer 1
46 Depth Bracket 1
47 Screw (M6 x 14) 1
48 Screw (M6 x 16) 1
49 Bearing (6000Z) 1
50 C-Ring (#12) 1
51 Rotor 1
52 Bearing (607Z) 1
53 Bearing Cover 1
54 Air Baffle Plate 1
55 Screw (ST4.8 x 60) 2
56 Stator 1
57 Housing 1
58 Screw (M5 x 58) 3
59 Carbon Brush Holder 2
60 Carbon Brush 2
61 Carbon Brush Cover 2
62 Nut (M5) 2
63 Right Handle 1
64 Cord Clamp 1
65 Screw (ST4.2 x 14) 2
66 Cord Sleeve 1
67 Power Switch 1
68 Power Cord/Plug 1
69 Hex Wrench 1
70 Screw (ST4.2 x 12) 1
71 Left Handle 1
72 Screw (ST$.2 x 16) 4
73 Screw (M5 x 25) 2
74 Laser Switch 1
