User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 14/17
INPUT CHARACTERISTICS: PSL-6C00V
VOLTAGE: 90 ~ 264 VAC FULL RANGE.
FREQUENCY: 47 ~ 63 Hz.
STEADY-STATE CURRENT: 15/7.5A AT ANY LOW/HIGH RANGE INPUT VOLTAGE
INRUSH CURRENT: 20A MAX. FOR 110 VAC , 40A MAX. FOR 220 VAC (AT 25 DEGREE C AMBIENT
COLD START)
PFC: UP TO THE TARGET OF 95% @230V, FULL LOAD
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT (A) REGULATION OUTPUT
VOLTAGE
MIN. MAX. LOAD LINE
OUTPUT RIPPLE &
NOISE MAX. [P-P]
+5V 1 25 ± 250mV ±1% 60mV
+12V1 1 50 ± 600mV ±1% 120mV
+12V2 1 50 ± 600mV ±1% 120mV
-12V 0 0.8 ± 600mV ±1% 120mV
+3.3V 1 25 ± 165mV ±1% 60mV
+5VSB 0.1 3.5 ± 250mV ±1% 60mV
REMARKS:
1. +5V AND +3.3V TOTAL MAX. POWER: 170W
2. +3.3V AND +5V AND +12V2 TOTAL MAX. POWER: 600W
3. TOTAL MAX. POWER: 1200W
SPECIFICATION:
TEMPERATURE RANGE: OPERATING 0 ℃ -- 40℃; STORAGE TEMPERATURE: -20℃ – 80℃
HOLD UP TIME: 18mS MINIMUM AT 90V FULL LOAD & NOMINAL INPUT VOLTAGE
EFFICIENCY: 81%-86% TYPICAL AT 115V, FULL LOAD
LEAKAGE CURRENT: 3.5 mA. MAX. AT NOMINAL VOLTAGE 264VAC
POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
OVER POWER PROTECTION: 110%~160%
OVER VOLTAGE PROTECTION: +3.3V →3.6~4.3V, +5V→5.5~6.5V, +12V1→13.2~15.6V, +12V2→
13.2~15.6V
OVER CURRENT PROTECTION: +3.3V →27.5~37.5A, +5V→ 27.5~37.5A, +12V1→55~75A, +12V2→55~75A
SHORT CIRCUIT PROTECTION: +3.3V, +5V, +12V1, +12V2, -12V
SAFETY: TUV, CB, CCC, RFI/EMI STANDARDS
EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
COOLING: 8 0mm DC FANS
I2C FEATURES (OPTIONAL)
DIMENSION: 220 (D) x 150 (W) x 86 (H) mm
