Specifications
Please refer to the specifications according to the actual product purchased.
INPUT CHARACTERISTICS: PSM-6550P/6600P
VOLTAGE: 90 ~ 264 VAC FULL RANGE.
FREQUENCY: 47 ~ 63 Hz.
INPUT CURRENT: 10.0 A FOR 115 VAC, 5.0 A FOR 230 VAC.
INRUSH CURRENT: 65 A MAX. FOR 115 VAC, 125 A MAX. FOR 230 VAC.
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT REGULATION OUTPUT OUTPUT
VOLTAGE
MIN.[A] MAX.[A] LOAD LINE RIPPLE & NOISE
MAX. [P-P]
5V 0.5 30
± 5% ± 1%
60mV
12V1 1.5 26
± 5% ± 1%
100mV
12V2 0 20
± 5% ± 1%
100mV
-12V 0 0.8
± 5% ± 1%
100mV
3.3V 0.5 30 +5, -5%
± 1%
60mV
+5VSB 0 2
± 5% ± 1%
60mV
REMARK: 12V TOTAL OUTPUT 40A MAX.
REMARK: TOTAL OUTPUT SHOULD NOT EXCEED 550W/600W FOR PSM-6550P/6600P.
*** WHEN PERFORMING CROSS REGULATION TEST, IT IS REQUESTED TO SET THE HIGHER OUTPUT
CHANNEL AT 90% MAXIMUM AND THE LOWER OUTPUT CHANNELS AT 20% MININUM OF RATED
SPEC.
TEMPERATURE RANGE: OPERATING 0 0 C --- 40 0 C, STORAGE –20 0 C --- 70 0 C.
HUMIDITY: 10 ~ 90 % RH.
HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & 90 VAC INPUT VOLTAGE.
DIELECTRIC WITHSTAND: INPUT / OUTPUT 1500 VAC FOR 1 MINUTE,
INPUT TO FRAME GROUND 1500 VAC FOR 1 MINUTE.
EFFICIENCY: 70% TYPICAL, AT FULL LOAD, 115VAC.
POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms.
OVER LOAD PROTECTION: 110 ~ 150% MAX.
OVER CURRENT PROTECTION:
+5V 33 A ~ 45 A, + 3.3V 33 A ~ 45 A, 12V1 19.8 A ~ 25.2 A
12V2 19.8 A ~ 25.2 A.
OVER VOLTAGE PROTECTION:
+5V 5.7V ~ 6.5V, 3.3V 3.9 ~ 4.3V, 12V1 13.6 ~ 15V
12V2 13.6 ~ 15V.
EMI: MEET FCC CLASS B, CISPR22 CLASS B.
SAFETY: UL 1950, CSA 22.2 NO/ 950, TÜV IEC 950.
REMOTE ON / OFF CONTROL.
SHORT CIRCUIT PROTECTION: SHUTDOWN AND LATCH.
BUILT-IN ACTIVE POWER FACTOR CORRECTOR.
DIMENSION: 86(H) X 150(W) X 160 (D) mm (STRETCH PS/2, EPS12V).
COOLING: ONE 80 BALL BEARING mm DC FAN.
