2

Workrite Ergonomics | 800.959.9675 www.workriteergo.com

Workrite Sierra HX™ 2-Leg Front-Crank Workcenters - Assembly Instructions

I

5

/

32

" Allen Wrench

Qty: 1

Parts grouped by carton

1

Verify that you have all the hardware and tools needed for the assembly

Check your cartons against the list above to verify that you have all the parts needed.

You will also need the following tools:

#2 tip Phillips screwdriver or drill bit

#3 tip Phillips screwdriver or drill bit

If you do not have a Workrite tabletop,

you will also need:

⅛” pilot drill bit

Lay out the Legs (E), Leg Braces (B, C,

and E), and Leg Caps (F) on the floor in

the proper location.

or

F

Leg Cap

Qty: 1

b

a

b

B

Long Brace

Qty: 1

D

Side Leg

Qty: 1

F

Leg Cap

Qty: 1

C

Short Brace

Qty: 2

D

Side Leg

Qty: 1

H

#12 x ¾" Pan Head

Sheetmetal Screw

Qty: 24

G

¼-20 x ⅝” Button

head Machine Screws

Qty: 20

For assembly of two-piece tops, please

refer to separate instructions.

A

Tabletop (size and shape differ for each model)

Qty: 1

J

Center Leg

Qty: 1

F

Leg Cap

Qty: 1

E

Side Brace

Qty: 1

E

Side Brace

Qty: 1

E

Side Brace

Qty: 1

B

C

F

E

D
