4
Vermont Castings, Majestic Products DVRT36/ 39/ 43
10002428
Fireplace Dimensions (Installed as Top Vent)
CFM188
Fig. 2 Fireplace specifications and framing dimensions.
5/8"
C
L
P - Rough Opening Width
7" Dia.
4" Dia.
5 ¹⁄₂ "
(140mm)
Rough
Opening
Height
Electrical
Access
Rough
Opening
Depth
Recessed
Nailing
Flange
Gas Line
Access
(178mm)
(102mm)
(16mm)
M
M
N
E
Q
C
A
F
D
G
O
I
J
K
C
L
O
I
J
2"
(51mm)
Gas Line
Access
2" (51mm)
4" (102mm)
R
Ref. DVRT36 DVRT39 DVRT43
A 36” (914mm) 39” (991mm) 43” (1092mm)
B 37
¹⁄₄
” (946mm) 37
¹⁄₄
” (946mm) 40” (1016mm)
C 34
¹⁄₄
” (870mm) 34
¹⁄₄
” (870mm) 37” (940mm)
D 21” (533mm) 21” (533mm) 23 ¹⁄₂ ” (597mm)
E 32
₇⁄₈
” (835mm) 35
₇⁄₈
” (911mm) 39
₇⁄₈
” (1012mm)
F 20” (508mm) 24
³⁄₈
” (619mm) 31” (787mm)
G 14
¹⁄₄
” (362mm) 15
³⁄₄
” (400mm) 16
¹⁄₄
” (412mm)
H 6” (152mm) 6” (152mm) 6” (152mm)
I 5
¹⁄₂
” (140mm) 5
¹⁄₂
” (140mm) 5
¹⁄₂
” (140mm)
J 7
³⁄₄
” (197mm) 8
¹⁄₂
” (216mm) 8
¹⁄₂
” (216mm)
K 10 ³⁄₄ ” (273mm) 12 ¹⁄₂ ” (318mm) 12 ¹⁄₂ ” (318mm)
L 18” (457mm) 19 ¹⁄₂ ” (495mm) 21 ¹⁄₂ ” (546mm)
Framing Dimensions
M 36” (914mm) 40” (1016mm) 44” (1118mm)
N 51” (1295mm) 56” (1422mm) 62 ¹⁄₄ ” (1581mm)
O 14 ¹⁄₂ ” (368mm) 16 ¹⁄₂ ” (419mm) 16 ¹⁄₂ ” (419mm)
P 36
¹⁄₂
” (927mm) 39
¹⁄₂
” (1003mm) 43
¹⁄₂
” (1105mm)
Q 35” (889mm) 35” (889mm) 37
³⁄₄
” (959mm)
R 25 ¹⁄₂ ” (648mm) 28” (711mm) 36 ¹⁄₈ ” (918mm)
