10. SPECIFICATIONS
FM Tuner
Frequency Range:
87.9 MHz to 107.9 MHz
Usable Sensitivity:
11 dBf
50dB Quieting Sensitivity:
17 dBf
Alternate Channel Selectivity:
75 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response ( ± 3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
530 kHz to 1710 kHz
Usable Sensitivity:
25 µ V
CD Player
Frequency Response ( ± 1 dB):
10 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
100 dB
Dynamic Range (1 kHz):
95 dB
Harmonic Distortion:
0.01%
MD Player
Frequency Response ( ± 2 dB):
20 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
90 dB
Dynamic Range (1 kHz):
85 dB
Harmonic Distortion:
0.01%
Notes:
• Specifications comply with EIA Standards.
• US and foreign patents licensed from Dolby Laboratories Licensing Corporation.
• Specifications and design are subject to change without notice for further improvement.
Audio
Maximum Power Output:
160 W (40 W × 4 ch) (EIAJ)
Continuous Average Power Output:
14 W × 4, into 4 Ω , 20 Hz to 20 kHz, 1%THD
Bass Control Action (30 Hz):
± 15 dB
Treble Control Action (10 kHz):
± 10 dB
Line Output Level (MD 1 kHz):
4 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable),
negative ground
Current Consumption:
Less than 15 A
Speaker Impedance:
4 Ω (4 Ω to 8 Ω allowable)
Weight / Source unit:
5.5 lb. (2.5 kg)
Weight / Remote control unit:
1 oz. (30 g) (including battery)
Dimensions / Source unit:
7 " (Width) × 3-15/16 " (Height) × 6 - 1/8 " (Depth)
[178 (W) × 100 (H) × 155 (D) mm]
Dimensions / Remote control unit:
1-3/4 " (Width) × 4-5/16 " (Height) × 1 - 1/8 " (Depth)
[44 (W) × 110 (H) × 27 (D) mm]
ERROR 2
ERROR 3
ERROR 2
ERROR 3
ERROR 2
ERROR 3
ERROR 6
ERROR H
ERROR 2
ERROR 3
ERROR 6
9. ERROR DISPLAYS
If an error occurs, one of the following displays is displayed.
Take the measures described below to eliminate the problem.
If an error display other than the ones described above appears, press the reset button. If the problem
persists, turn off the power and consult your store of purchase.
Error Display Cause Measure
This is a failure of CD deck’s mechanism
and consult your store of purchase.
Replace with a non-scratched, non-warped
disc.
This is a failure of MD deck’s mechanism
and consult your store of purchase.
Replace with a non-scratched,
non-warped-disc.
This is a failure of CD changer’s mecha-
nism and consult your store of purchase.
Replace with a non-scratched, non-warped
disc.
Eject the disc then reload it properly.
Lower the surrounding temperature and
wait for a while to cool off MD changer.
This is a failure of MD changer’s mecha-
nism and consult your store of purchase.
Replace with a non-scratched, non-warped
disc.
Load a pre-recorded MD in the MD
changer.
A CD is caught inside the CD deck and is
not ejected.
A CD cannot be played due to scratches,
etc.
An MD is caught inside the MD deck and
is not ejected.
An MD cannot be played due to scratches,
etc.
A CD inside the CD changer is not loaded.
A CD inside the CD changer cannot be
played due to scratches, etc.
A CD inside the CD changer cannot be
played because it is loaded upside-down.
Displayed when the temperature in the MD
changer is too high and playback has been
stopped automatically.
An MD inside the MD changer is not
loaded.
An MD inside the MD changer cannot be
played due to scratches, etc.
Displayed when a non-recorded MD is
loaded in the MD changer.
CD
MD
CD changer
MD changer
