GENERAL INFORMATION
The Model V100 converts 220/240 volt foreign electricity to North
American standard 110/120 volts. Its grounded step-down transformer
produces a true sine wave output for use with electronic devices rated
up to a maximum of 100 watts. See examples below.
Answering Machines
Battery Chargers for:
Portable Computers, Camcorders, Cordless Telephones, Power
Tools
Health Appliances
Portable Computers and Peripherals:
Monitors, Printers, External Storage Devices
Portable Fax Machines
Mini Stereo Systems
Small Personal Appliances
DO NOT USE with ANY electronic devices, whether listed above or
not, that require more than 100 watts.
INSTRUCTIONS
How to use your Voltage Valet 100 Watt Grounded
Voltage Converter
1. Read all instructions before
using converter.
2. Turn the ON/OFF switch on
the voltage converter to the
OFF position.
3. Insert plug from your
110/120 volt device into the
converter plug receptacle.
NOTE: Some wall mounted
electronic devices may
require the use of a short extension cord to clear the
ON/OFF switch.
4. Plug converter into a 220/240 volt electrical outlet. Turn the ON/OFF
switch to the ON position. The operation light will come on and you
are ready to turn on your device. See above diagram. NOTE: If the
operation light fails to illuminate replace the fuse. See figure below.
5. For best results unplug your converter from the wall outlet when
not in use.
IMPORTANT. PLEASE READ.
• The Model V100 is equipped with a safety fuse that will “blow” if the
converter is used with devices exceeding its 100 watt rating. If this
occurs, unplug the converter from the electrical outlet and allow to
cool. Replace fuse with a 1 Amp 250 Volt 5mm x 20mm slow blow fuse.
• Before using your Voltage Valet converter check to see if the electrical
outlet is 100/110/120 volts or 220/240 volts. The converter will not
work in a 100/110/120 volt outlet.
Operation
Light
On/Off
Switch
Plug
Receptacle
Top View Bottom View Plug
Continental
Europe Pins
Fuse
Compartment
