Vision 250e (left-hand side) – Vinten Radamec Vision 250E User Manual
Page 5
5
(1)
Slide plate clamp
(2)
Telescopic pan bar
(3)
Encoder connector
(4)
Balance knob
(5)
Centre lock
(6)
Illuminated level bubble
(7)
Ambient light level sensor
(8)
Digital display
(9)
Switch for illuminated level bubble, drag knob scales and digital display
(10)
Tilt drag adjustment knob
(11)
Slide lock release
(12)
Camera mounting screws
(13)
Slide plate
Vision 250E (Left-Hand Side)
(1)
(2)
(3)
(4)
(5)
(9)
(7)
(6)
(8)
(10)
(11)
(12)
(13)
