Safety - read this first
Warning Symbols in this Operators Guide
Where there is a risk of personal injury, injury to others, or damage to the pan
and tilt head or associated equipment, comments appear, highlighted by the
word WARNING! and supported by the warning triangle symbol.
Technical data
Weight (complete with pan bar) 7.35 kg (16.2 lb)
Height to mounting face 185 mm (7.3 in.)
Length 182 mm (7.2 in.)
Width 291 mm (11.5 in.)
Load capacity 10 - 33 kg (22 - 73 lb) - See balance graph (Fig 3)
Tilt range ±90°
Pan range 360°
Tilt resolution 533,333 counts per 360°
Pan resolution 696,667 counts per 360°
Power requirement - Encoders 5V dc ±10%
Pedestal/tripod fixing Four-hole/Quickfix flat base
Further information
For further information or advice regarding this pan and tilt head, please contact Vinten Broadcast
Limited, your local Vinten distributor or visit our website.
For full details on maintenance and spare parts, please refer to the Vision 250E Pan and Tilt Head
Maintenance Manual and Illustrated Parts List (Publication Part No. 3793-9) This is obtainable
from Vinten Broadcast Limited or your local Vinten distributor. For information on-line, visit our
website at
www.vinten.com.
