8
Installation
Mounting the FVR Box
To mount the FVR box to a Fusion head, any fitted payload must be
removed and it must be dismounted from its support. All work should
be carried out in a workshop environment on a suitable work surface.
The head should be placed on its side or back cover to allow access to
the base of the mounting plate area, then proceed as follows:
WARNING! Heavy 24.5kg (54lbs).
Do not lift the head by the cradle.
Two person lift may be required.
24.5 kg
54lbs
1
5 mm
WARNING! Do not attempt to lift or carry the head by using
the mounting bracket or the FVR box.
2
4 mm
