435H Technical Manual Page 9
5. DRAWINGS
5.1. Build Standard
TYPE 435H PAN + TILT HEAD (HK 435-103-0001)
The type 435H heavy duty (70kg) P+T Head with increased damping is based on the
HK 435-101-0002DA build standard and contains the following sub assemblies:
Suppression P.C.B. : HK 707-182-0003
Clutch P.C.B. : HK 707-423-0002
(P / T brake clamp : HK 435-103-4001)
The drawings for the Head and its sub-assemblies are:
TITLE
DRAWING TYPE DRAWING NUMBER ISSUE
Type 435H P+T Head Gen. Assembly HK 435-103-0001W (2) C
Type 435H P+T Head Connections HK 435-001-2002W E
Suppression P.C.B. PCB Assembly HK 707-182-0003Y A
Suppression P.C.B. PCB Circuit HK 707-182-2003Y A
Clutch Drive P.C.B. PCB Assembly HK 707-423-0002T C
Clutch Drive P.C.B. PCB Circuit HK 707-423-2002T B
NOTES
1.
Drawings in parenthesis in the Build Standard (Section 5.1) are not included in
this Manual.
2.
All drawings are photo-reduced to A3 size for inclusion in the Technical Manual.
The exception is those drawings, which do not photo-reduce well.
