Vintage Cellars DA Cooling System User Manual
Da cooling system - typical installation

Ceiling
Fan coil
Wall
Line set
Drain line
Condensing unit
Floor
Fan coil is bolted to ceiling in center of room for proper air flow.
Keep line set as short and direct as possible. Excessive number of turns
will cause refrigerant flow problems. This would cause early failure of compressor
Drain line must always flow down hill. Return to condensing unit on systems
up to 3600 btu or drain to a point allowed by local code.
System is controlled by a pump down solenoid so no wiring is required
between fan coil and condensing unit.
DA Cooling System - Typical Installation
