Vintage Cellars TX60U-IT La Crosse Alerts User Manual
Page 2
MOUNTING
THE TX60U-IT TEMPERATURE & HUMIDITY SENSOR
The sensor can be mounted onto a wall with the use of screws
MOUNTING WITH SCREWS
1.
Remove the mounting bracket from the sensor.
2.
Place the mounting bracket over the desired location.
3.
Mark the mounting surface with a pencil through the two screw holes of
the bracket.
4.
Screw the mounting bracket onto the mounting surface. Ensure that the
screws are tight against the bracket.
5.
Insert the sensor into the bracket.
TABLE STANDING AND OTHER MOUNTING OPTIONS
With the mounting bracket installed at the bottom
or on the top of the sensor, the user can
place it on any flat surface.
Note:
Before permanently fixing the sensor mounting bracket, place all
units in the desired locations to check that the outdoor temperature
& humidity readings are receivable. In event that the signal is not
received, relocate the sensor or move them slightly as this may help
the signal reception.
MAINTENANCE AND CARE
Extreme temperatures, vibration, and shock should be avoided to prevent
damage to the units.
Clean displays and units with a soft, damp cloth. Do not use solvents or
scouring agents; they may mark the displays and casings.
Do not submerge the sensor case in water.
Avoid kinking the temperature probe cable.
Immediately remove all low powered batteries to avoid leakage and damage.
Opening the casings invalidates the warranty. Do not try to repair the unit.
Contact La Crosse Technology® for repairs.
SPECIFICATIONS
Device sensor:
Temperature range:
-40°F to 140°F with 0.2°F resolution
“OFL” displayed if outside this range.
Humidity measuring range:
3% to 99%
Transmission range:
200 feet (60.96 m) in open space
**Optional probe sensor:
Temperature range:
-40°F to 140°F with 0.2°F resolution
“OFL” displayed if outside this range, and
displayed “nC” if probe is not connected.
Power Supply:
Temperature transmitter :
2 x AAA, IEC LR03, 1.5V
Battery life cycle:
Approximately 24 months
Recommended battery type:
Alkaline
Dimensions (H x W x D):
5.23" x 0.76" x 1.44"
WARRANTY INFORMATION
La Crosse Technology, Ltd provides a 1-year limited warranty on this product
against manufacturing defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only on
products purchased and used in North America and only to the original
purchaser of this product. To receive warranty service, the purchaser must
contact La Crosse Technology, Ltd for problem determination and service
procedures. Warranty service can only be performed by a La Crosse
Technology, Ltd authorized service center. The original dated bill of sale must
be presented upon request as proof of purchase to La Crosse Technology, Ltd
or La Crosse Technology, Ltd’s authorized service center.
La Crosse Technology, Ltd will repair or replace this product, at our option and
at no charge as stipulated herein, with new or reconditioned parts or products if
found to be defective during the limited warranty period specified above. All
replaced parts and products become the property of La Crosse Technology, Ltd
and must be returned to La Crosse Technology, Ltd. Replacement parts and
products assume the remaining original warranty, or ninety (90) days,
whichever is longer. La Crosse Technology, Ltd will pay all expenses for labor
and materials for all repairs covered by this warranty. If necessary repairs are
not covered by this warranty, or if a product is examined which is not in need or
repair, you will be charged for the repairs or examination. The owner must pay
any shipping charges incurred in getting your La Crosse Technology, Ltd
product to a La Crosse Technology, Ltd authorized service center. La Crosse
Technology, Ltd will pay ground return shipping charges to the owner of the
product to a USA address only.
Your La Crosse Technology, Ltd warranty covers all defects in material and
workmanship with the following specified exceptions: (1) damage caused by
accident, unreasonable use or neglect (including the lack of reasonable and
necessary maintenance); (2) damage occurring during shipment (claims must
be presented to the carrier); (3) damage to, or deterioration of, any accessory or
decorative surface; (4) damage resulting from failure to follow instructions
contained in your owner’s manual; (5) damage resulting from the performance
of repairs or alterations by someone other than an authorized La Crosse
Technology, Ltd authorized service center; (6) units used for other than home
use (7) applications and uses that this product was not intended or (8) the
products inability to receive a signal due to any source of interference.. This
warranty covers only actual defects within the product itself, and does not cover
the cost of installation or removal from a fixed installation, normal set-up or
adjustments, claims based on misrepresentation by the seller or performance
variations resulting from installation-related circumstances.
LA CROSSE TECHNOLOGY, LTD WILL NOT ASSUME LIABILITY FOR
INCIDENTAL, CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR
DAMAGES ASSOCIATED WITH THE OPERATION OR MALFUNCTION OF
THIS PRODUCT. THIS PRODUCT IS NOT TO BE USED FOR MEDICAL
PURPOSES OR FOR PUBLIC INFORMATION. THIS PRODUCT IS NOT A
TOY. KEEP OUT OF CHILDREN’S REACH.
This warranty gives you specific legal rights. You may also have other rights
specific to your State. Some States do no allow the exclusion of consequential
or incidental damages therefore the above exclusion of limitation may not apply
to you.
For warranty work, technical support, or information, please contact:
La Crosse Technology, Ltd
2817 Losey Blvd. S.
La Crosse, WI 54601
Create an account and activate devices using a computer or tablet:
www.lacrossealerts.com
If you have lost your Activation Card with the
Activation Key, please contact customer support for
assistance:
Support:
www.lacrossetechnology.com/support/alerts
Phone: (608) 785-7920
For online product information: www.lacrossetechnology.com/alerts
FCC DISCLAIMER
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful interference.
(2)
This device must accept any interference received, including
interference that may cause undesired operation.
All rights reserved. This handbook must not be reproduced in any form, even in
excerpts, or duplicated or processed using electronic, mechanical or chemical
procedures without written permission of the publisher.
This handbook may contain mistakes and printing errors. The information in
this handbook is regularly checked and corrections made in the next issue. We
accept no liability for technical mistakes or printing errors, or their
consequences.
All trademarks and patents are acknowledged.
LT04192012
