* * I M P O R T A N T – S P L I T C O N F I G U R A T I O N S * *
I N S T A L L E R S M U S T F I L L O U T T H I S S H E E T A N D F A X T O
7 0 7 . 7 9 4 . 8 0 0 5 O R S C A N / E M A I L T O I N F O @ C E L L A R P R O . C O M
T O A C T I V A T E T H E W A R R A N T Y .
Installing Air Handler Split Systems requires an experienced professional and adherence to industry practices
which are described in the manual. To activate the warranty, the system must be installed properly. In order for us
to assess and approve the installation, the installing technician must complete the page below. The page can be
faxed to 707.794.8005 or emailed to info@cellarpro. We will contact you once we receive and review this sheet.
Technician Information
Name Phone
System Information Piping Information
Customer Name R-134a system charge lb.
Condensing Unit Model # Line-set length – ft.
Condensing Unit Serial # Liquid line diameter – OD
Evaporator Model # Suction line diameter - OD
Evaporator Serial #
Operational Data
Take the following measurements during a normal refrigeration cycle, once the cellar has
pulled down to the set-point temperature. Make sure the compressor is running when
recording the data.
Evaporator Comment
Air temperature at Evaporator coil
inlet/outlet
°F/°F 8-10°F TD
Evaporator fan speed (High / Med / Low)
Evaporator power supply voltage & amps V & A
103-127 V – check
nameplate amps
Condensing Unit
Air temperature at Condenser coil inlet &
outlet
°F/°F 20-30°F TD
Condenser fan status (ON / OFF)
Suction pressure at suction service valve PSIG 25-35 PSIG
Suction temperature at suction service valve °F 20°F Superheat Min.
Liquid pressure at liquid service valve PSIG 105-180 PSIG
Liquid temperature at liquid service valve °F 10-20°F Subcooling
Condensing Unit power supply voltage &
amps
V & A
103-127 V – check
nameplate amps
