Brightness
•
4000 ANSI lumens (2-lamp mode)
• 2400 ANSI lumens (1-lamp mode)
• 85% brightness uniformity
Contrast Ratio
•
Over 900:1 on/off
Resolution
•
3 x 1.2" p-Si Active Matrix TFT High Aperture
LCD panels with Micro Lens Array
• True WXGA 1366 x 768 chip resolution
• 8-bit color resolution offering 16.7 million
displayable colors
Dynamic Scaling
•
Digital scaling of VGA - SXGA resolutions
• Digital de-interlacing of STV, DTV and HDTV
formats with Digital Interpolation Technology
(DIT) automatic with 2:3 pull-down
Horizontal Frequency
•
15 to 120 kHz
• Automatic frequency control
Vertical Freqency
•
50 to 120 Hz
• Automatic frequency control
Dot Clock
•
230MHz
Standard Projection Lens
•
A full suite of short/medium/long fixed and
zoom optional lenses
• Power adjustable zoom, focus, up/down,
lens shift
• Power lens shift U/D ratio of up to
10:0-0:10
• I mage elevation adjustment: up 6.9 degrees
• Screen size 40" - 600" (0.15 m to 15.24 m )
diagonal
Modular Inputs
•
Input 1 (removable):
• Analog RGB, (15-pin D-sub), audio input
(2 x RCA-R, L/mono),(Control - 8-pin
mini-DIN x1)
• Input 2 (removable):
• Analog RGB with 5 BNC for RGBHV, YpbPr
and YcbCr, audio input (2x RCA–R,L /mono),
Control (8-pin mini-DIN x 1)
• Input 3 (removable):
• Composite (2 x BNC), S-video, Y,C (4-pin mini-
DIN), audio – (2 x RCA -R, L/mono)
Outputs
•
Two built-in 3W speakers (per channel)
and amplifier
• Audio output RCA x 2
Source Compatibility
•
Compatible with VGA, SVGA, XGA, WXGA,
SXGA, UXGA and MAC sources
• Accepts Composite Video, S-Video and
component video from VCR, DVD, Laser Disc
players and video cameras
• Auto-detects PAL, PAL M, PAL N, NTSC,
NTSC4.43 and SECAM video standards
• Compatible with DTV/HDTV formats, 480 30i,
480 30p, 720p, 720 60p, 1035 30i, 1080 25i
and 1080 30i and 1035i
• HDTV compatible, 800 TV lines horizontal
resolution
• Digital Visual Interface (DVI-D) compatible
Enhanced Feature Set
•
Progressive scan video decoding
• 3-D digital noise reduction
• 2-lamp or 1-lamp mode, user-selectable
from menu
• Motorized zoom and focus
• Motorized lens shift (up and down)
• Digital zoom function (max. x49)
• Digital keystone function (+/- 30 degrees)
• Power management function
Control/Networking
•
Automatic Multi-Scanning Set-up System
(AMSS) (phase/tracking/position)
• USB Type B
• Remote control jack
• RS232-C communications port via 9-pin
D-sub terminal (in/out)
• Wire remote control
• IR remote keypad with mouse and laser
pointer
• Front and rear IR receivers
• Remote mouse control
• ChristieNET ™ control and monitoring via
HTML and SNMP (optional)
Graphical User Interface
•
Easy set-up and intuitive multi-language on
screen displays (OSD)
(English/German/French/Spanish/Italian/
Portuguese/Dutch/Swedish/Chinese/Korean/
Japanese)
• Direct key status function
• Choice of image aspect ratios (native 16:9
and 4:3)
• Blue back display
• Standby on-screen logo display
• Picture reverse scans function (left/right and
top/bottom) for front, rear and inverted
projection
Lamp Specification
•
Two 265W UHP lamps
• 1000 hours lamp life at maximum brightness
• Lamp life warning indicators
• User replaceable lamp
Power Requirements
•
Universal power AC 100 - 240V, 50/60Hz
• Operating voltage: 90-264V (100-120V/
200-240V +/- 10%)
• Power consumption: 660 W maximum
• Thermal dissipation: 2700 BTU/hr
• Operating temperature: 5 to 35º
(storage: -10 to 60º)
• Operating humidity: 20 - 80%
(storage 0 - 90%)
• Acoustic noise level: 45dBA (Auto fan control
for noise level reduction)
Weight and Size
•
45.2 lbs (20.5 kg)
• 17.3" (W) x 8.9" (H) x 23.8" (D)
• 439mm (W) x 230mm (H) x 605mm (D)
Standard Accessories
•
Real Color Manager (RCM) user-definable
gamma software
• Wireless/wired remote controller with mouse
control and laser pointer (two "AA" type
batteries and cable included)
• User manual
• Computer cable (D-sub-15 – D-sub-15)
• Mac/VGA adapter
• Mouse control cable (PS/2, Serial and MAC)
• Dust cover
• AC cord x 2 (UL and European)
Optional Accessories
•
Fixed lenses: 1.2:1, 1.8:1 and 10.3:1
• Zoom lenses: 2.0-2.65:1, 2.95-3.85:1, 3.85-
5.2:1, 5.2-6.8:1, 6.8-8.8:1 zoom lens
• Digital Visual Interface (DVI) module
• 5BNC interface module
• Y/C video interface module
• D-sub-15 interface module
• Digital HD-SDI interface module
• SDI digital interface module [tbd – needs new
electronics from L6/LX65]
• 10-bit Faroudja ® interface module
• Lamp module
• Shipping case
Regulatory Approvals
•
Complies with all relevant world-wide EMC
and safety standards
• The product complies with FCC class A, CE
mark and safety requirements IEC950
(EN60950), UL1950 / cUL
Warranty
•
Product warranty, 3 years parts and labor
(excluding lamp)
Reliability
•
Mean time between failure (MTBF) over
28,000 hrs
LW40U
•
38-VIV210-02
