Vintage Cellars DIAB-L-36x36 EcoWineracks - Manual (Page 2)

Step Three.
Carefully lay the assembled X-Interlocks on the floor.
There is no difference between front and back of
interlocks so front is same as back.
Step Four.
Carefully lay the assembled X-Interlocks on the floor.
There is no difference between front and back of
interlocks so front is same as back.
Slide the perimeter frame gently over the X-lnterlocks
until the frame touches the floor and rests on face face
frame trim. Grab the frame and rotate up so the larger
face trim (2") is at the bottom. If interlocks shifted during
rotation, gently slide so they are flush to the back of the
cabinet.
Step Five.
Secure to wall with (2) L-Brackets included. If
wall framing cannot be located, use screw plastic
anchors provided and go through drywall.
DIAB-L-36X36 ASSEMBLY 41812013
